廈門供應 全新原裝\力士樂\閥\3DREPE6C-21 25EG24N9K31 A1V

咨詢電話：18965852209   資詢QQ：2277643779  （小崔）

類型 3DREP 和 3DREPE 比例減壓閥,三通型號

規格 6

組件系列 2X

最大工作壓力 100 bar

最大流量 15 l/min

– 直動式比例閥用于控制壓力和流向

– 通過帶對中螺紋和可拆卸線圈的比例線圈進行操作

– 底板安裝：安裝面符合 ISO 4401

– 手動操控，可選

– 彈簧對中控制閥芯

– 類型 3DREPE 帶集成控制電子元件

– 類型 3DREP 的外部控制電子元件：

  模擬放大器類型 VT-VSPA2-1-2X/…，采用歐洲板卡標準

（單獨訂購），請參閱第 5 頁

  數字放大器類型 VT-VSPD-1-1X/…，采用歐洲板卡標準

（單獨訂購），請參閱第 5 頁

  模塊化設計的電動放大器類型 VT 11118（單獨訂購），

三通減壓閥類型 3 DREP 6.. 由比例線圈直接操作。它用于將電氣輸入信號轉化為比例壓力輸出信號。比例線圈是帶濕式柱銷的可控直流線圈，帶對中螺紋和可拆卸線圈。這些線圈可選擇性地由外部控制電子元件（類型 3DREP）或內部控制電子元件（類型 3DREPE）進行驅動。

設置：

閥基本構成包括：

– 帶安裝面的閥體（1）

– 控制閥芯（2），帶壓力測量閥芯（3，4）

– 帶對中螺紋的線圈（5，6）

– 可選集成控制電子元件（7）

功能：

通過比例線圈設置 A 或 B 中的壓力。具體壓力取決于電流。線圈（5，6）斷電后，控制閥芯（2）將通過壓縮彈簧（8）保持在中心位置。油口 A 和 B 連接到 T，以便液壓油可以不受阻擋地流入油箱。通過為比例線圈（例如線圈 "a"（5））通電，壓力測量閥芯 （3）和控制閥芯（2）將向右移動。這樣將通過具有漸進流量特性的節流截面，打開從 P 到 B 及從 A 到 T 的連接。在通道 B 中形成的壓力以壓力測量閥芯（4）的表面作用于控制閥芯，并與磁力相反。壓力測量閥芯（4）受線圈 "b" 支撐。如果壓力超過線圈 "a" 上設置的值，將逆磁力方向回推控制閥芯 （2），并建立 B 與 T 的連接，直到重新獲得設置的壓力。壓力與線圈電流成比例。在關閉線圈后，控制閥芯（2）將通過壓縮彈簧（8）返回中心位置。通過可選的手動操控（9，10），可使控制閥芯（2）在無線圈通電的情況下發生位移。

一般

閥類型3DREP 重量kg 2.0 3DREPE 重量kg 2.2

安裝位置任何位置，最好為水平

存儲溫度范圍°C –20 至 +80

環境溫度范圍°C –20 至 +70 –20 至 +50

推薦型號：

R9003753583DREP6C-1X/16A24N9Z4M

R9003880923DREP6C-1X/25A24N9Z4V

R9004088563DREP6C-1X/25A24NZ4M

R9004088573DREP6C-1X/25A24Z4M

R9004088583DREP6C-1X/25A24NZ4V

R9004088593DREP6C-1X/25A24Z4V

R9004447203DREP6C-1X/45A24N9Z4M

R9004878483DREP6C-1X/25A24N9Z4M

R9004941413DREP6C-1X/16A24Z4M

R9004941433DREP6C-1X/16A24NZ4M

R9004941533DREP6C-1X/16A24K4M

R9004941553DREP6C-1X/16A24NK4M

R9004941653DREP6C-1X/25A24K4M

R9004941673DREP6C-1X/25A24NK4M

R9004941773DREP6C-1X/45A24Z4M

R9004941783DREP6C-1X/45A24NZ4V

R9004941793DREP6C-1X/45A24NZ4M

R9004941893DREP6C-1X/45A24K4M

R9004941903DREP6C-1X/45A24NK4V

R9004941913DREP6C-1X/45A24NK4M

R9004984813DREP6C-1X/25A12NZ4M

R9004984853DREP6C-1X/25A12NK4M

R9005471003DREP6C-1X/25A24N9K4M

R9005500963DREP6C-1X/16A24N9K4M

R9005513303DREP6C-1X/25A24NK4V

R9005594403DREP6C-1X=25A24NZ4M=LB

R9005737503DREP6C-1X/25A24N9K4V

R9005895643DREP6C-1X/16A24N9Z4V

R9007350263DREP6C-2X/25EG24JD/M

R9007374803DREP6C-2X=25EG24JD/M=00

R9007531063DREP6C-2X/25EG24N6K4/M

R9007531073DREP6C-2X=25EG24N6K4/M=00

R9007540623DREP6C-2X/25EG24N9K4/M=PL

R9007549603DREP6C-2X/25EG24N5K4/M

R9007549613DREP6C-2X=25EG24N5K4/M=00

R9007551113DREP6C-2X/25EG24N9K4/M-20

R9007551223DREP6C-2X=25EG24N9K4/M-20=00

R9007551233DREP6C-2X=25EG24K4/M-20=00

R9007690543DREP6C-2X=25EG24N9K4/M-20=PL

R9007775253DREP6C-1X/45A12NK4M

R9009122333DREP6C-1X/45A24N9Z4V

R9009295293DREP6C-2X/25EG24N9K4/V

R9009302673DREP6C-2X=25EG24N9K4/V=00

R9009321543DREP6C-2X/25EG24K4/V

R9009352183DREP6C-2X=25EG24K4/V=00

R9009396563DREP6C-1X/25A24K4V

R9009442313DREP6C-2X/16EG24N9K4/V

R9009442323DREP6C-2X=16EG24N9K4/V=00

R9009450173DREP6C-2X/16EG24N9K4/V-6

R9009450183DREP6C-2X=16EG24N9K4/V-6=00

R9009458283DREP6C-2X=25EG24N9K4/V-589=00

R9009474443DREP6C-2X/45EG24N9K4/V

R9009474453DREP6C-2X=45EG24N9K4/V=00

R9009509043DREP6C-2X=25EG24K4/V-589=00

R9009525073DREP6C-1X/16A24K4V

R9009528363DREP6C-1X/16A24NK4V

R9009544193DREP6C-2X/16EG24K4/M

R9009544203DREP6C-2X/25EG24K4/M

R9009544213DREP6C-2X/45EG24K4/M

R9009544213DREP6C-2X/45EG24K4/M

R9009544943DREP6C-2X=16EG24K4/M=00

R9009544953DREP6C-2X=25EG24K4/M=00

R9009544963DREP6C-2X=45EG24K4/M=00

R9009557963DREP6C-2X/45EG24N9K4/M

R9009558873DREP6C-2X/25EG24N9K4/M

R9009561003DREP6C-2X/16EG24N9K4/M

R9009561013DREP6C-2X=25EG24N9K4/M=00

R9009570263DREP6C-1X/16A24NK4M-6

R9009580363DREP6C-2X=45EG24N9K4/M=00

R9009592513DREP6C-2X/25EG24NJK31/M

R9009594203DREP6C-2X=25EG24N9K4/M=LB

R9009594323DREP6C-1X=25A24NK4M=LB

R9009597413DREP6C-1X/45A24N9K4M

R9009618203DREP6C-2X/25EG24NJK31/V

R9009619463DREP6C-2X=16EG24N9K4/M=00

R9009625493DREP6C-2X=25EG24NJK31/V=00

R9009669913DREP6C-1X/45A24N9K4V

R9009677023DREP6C-2X/45EG24JK31/M

R9009720533DREP6C-2X=25EG24NJK31/M=00

R9009739893DREP6C-1X/16A24N9K4V

R9009749563DREP6C-2X/25EG24JK31/M

R9009753803DREP6C-2X=25EG24JK31/M=00

R9009784823DREP6C-2X/16EG24K4/V

R9009785533DREP6C-2X=16EG24K4/V=00

R9010087473DREP6C-2X=25EG24NK4/M-20=00

R9010089533DREP6C-2X=25EG24NK4/M-20=PL

R9010157963DREP6C-2X=25EG24JK31/V=00

R9010157973DREP6C-2X/25EG24JK31/V

R9010476983DREP6C-2X=25EG24N6JK31/M=00

R9010476993DREP6C-2X/25EG24N6JK31/M

R9011081143DREP6C-2X=45EG24NJK31/M=00

R9011081173DREP6C-2X/45EG24NJK31/M

R9011137323DREP6C-2X=25EG24N6JK10/V-899=00

R9011137353DREP6C-2X/25EG24N6JK10/V-899

R9011956263DREP6C-2X=25EG24K4/M-674=00

R9011956273DREP6C-2X/25EG24K4/M-674

R9012059873DREP6C-2X/25EG24N9K4/M-674

R9012059903DREP6C-2X=25EG24N9K4/M-674=00

R9012278753DREP6C-2X/25EG24N9K4/V-674

R9012278793DREP6C-2X=25EG24N9K4/V-674=00
