產品認證	rohs
計量單位	個
額定電流	1.5
額定電壓	125
環境溫度	-40+80
適用范圍	RJ45帶變壓器網絡接口
殼體材質	銅
導電體材質	磷青銅鍍金
品牌	YL
型號	TM-126XXGX2 8p8c
加工定制	是
孔位數	8

Electrical: Current Rating:1.5AMPS Voltacge Rating:125VAC Insulation Resistance:500MΩ Min Withstand Voltage:AC 1500V AC 1500V 50Hz or 60Hz 6s Contact Resistance:20mΩ Max Mechanical: Mating Force:2.2KG.F Max Retention Strength:7.7Kg Between jack and plug Durability:750Mating cycles Mini MATERIAL: Housing: LCP(UL94V-0) Gold Needle: Phosphor bronze after first nickel plating gold-plated Gold Plating: 6μ inch, 15μ inch, 30μ inch, 50μ inch Operation Temperature: -40℃~85℃ Storage Temperature: 0℃~70℃
